SENSITECH TempTale® Ultra
•Supports up to six temperature alarm settings
• Fully validated for the life sciences market
• There is no need to label dangerous goods in accordance with IATA’s Dangerous Goods Regulations
Free shipping on orders over $50!
- Satisfaction Guaranteed
- No Hassle Refunds
- Secure Payments
Description
Key TempTale Ultra Features
• Thin 12.5mm housing—easily slips into standard packaging
• Large LCD screen with clear indication of alarm status and
trip visibility
• Up to six programmable alarms, including MKT and
Trip Duration
• Single or Multiple Use recording options
• Increased download performance—up to 5X faster
download speeds
• USB interface enables direct download to software
• PDF configurable reports capable of supporting local time
zones and five languages for receiving sites
• Shipment details can be written to the device and
subsequently displayed on the PDF
• Option to Write Protect USB flash drive for virus protection
SENSITECH-Templale.Ultra-datasheet.pdf
Additional information
| Brand | SENSITECH |
|---|---|
| Model | TempTale® Ultra |
| Monitoring Recording Options | Single Use, Single-Use with User Programmable Overwrite, or Multiple Use |
| Temperature Measurement Range | -30oC to + 70oC |
| Temperature Accuracy Range | ± 0.5oC from -10oC to 45oC; ± 1.0oC from 45oC to 70oC; ± 1.0oC from -30oC to -10oC |
| Temperature Resolution | 0.1oC/F over full temperature measurement range |
| Data Memory Type | Non-volatile 16K Flash memory |
| Data Storage Capacity | 16,000 data points (16K) |
| Battery Life / Type | 12 months operating life / 3.0v coin cell lithium battery – non-replaceable; |
| Data Sampling Interval | Programmable from 30 seconds up to a maximum of 120 minutes |
| Water Resistant Housing | IP64 (with protective cap over USB connector) |
| Start Up Delay | 0 minutes to 24 hours |
| Programmable Alarms | Programmable high and low limits -> alarm is triggered when temperature exceeds set limits; |
| Alarm Delay Time Thresholds | Single event (continuous) or cumulative |
| LCD Indicators | Started, start-up delay, running, stopped; Alarm status: OK ( ), Alarmed ( ); Trip summary data |
| Start Up Options | Manual push button or automatic launch option |
| Dimensions | 108mm L x 50.2mm W x 12.5mm H; Multi-Use: 108mm L x 50.2mm W x 15.2mm H |
| Weight | 51g (1.8 oz); Multi-Use: 65g (2.3 oz.) |
| Quality Assurance Certifications | CE, UKCA, RTCA – D016ØG compliant, RoHS compliant, Response time tested to U.S. Pharmacopeia (USP) <1118> |
| Minimum System Requirements | Windows® PC w/ Windows® 7 or higher; Adobe® Reader 9.0 or higher |
| Data Analysis and Cold Chain Continuous Improvement Software | TempTale Manager® Desktop 8.0 or higher; ColdStream® Select |
| Computer Interface | USB 2.0, A-type plug |
| Ship air, ground, ocean in accordance with – | IATA Dangerous Goods Regulations; UN 3091, Packing Instruction 970 Section II – Excepted Lithium Metal and Lithium |
