DeltaTrak.ThermoTrace® BLE Infrared Thermocouple Probe Combo Thermometer-15039-01

  • Lightweight, compact, 2-in-1 design
  • Thermocouple probe for internal product temperature
  • Infrared for instant non-contact surface measurement
  • Multi-beam laser for accurate targeting
  • Ideal for extremely hot areas, moving objects, hard to reach places
  • Verify HACCP check points
  • Min/Max memory in IR mode
  • NSF Certified, NIST traceable calibration
  • Fast 3 second thermocouple reading
  • Instant infrared reading
  • Low battery indicator

Free shipping on orders over $50!

  • Check Mark Satisfaction Guaranteed
  • Check Mark No Hassle Refunds
  • Check Mark Secure Payments
GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
Categories: , ,

Description

Applications: Ideal for extremely hot areas, moving objects, hard to reach places
This fast, accurate thermometer is ideal for use anywhere food is processed, prepared, handled, served, packed, stored, shipped and received. The sharp tip thermocouple probe measures internal temperature, while the infrared sensor allows users to take instant surface temperature without touching, contaminating or causing damage. It is also ideal for measuring extremely hot areas, moving objects and hard to reach places. The unique multi-beam laser sighting ensures accurate aim at the target and provides an easy way to verify HACCP check points.

DeltaTrak.15039-01-datasheet.pdf





Additional information

Brand

DeltaTrak
Model

15039-01
Specifications

ThermoTrace BLE Infrared Thermocouple Probe Combo Thermometer
Field of View

8:1
Infrared Measurement Range

-76°F to 662°F (-60°C to 350°C)
Probe Measurement Range

-76°F to 662°F (-60°C to 350°C)
Operating Range

32°F to 122°F (0°C to 50°C)
Infrared Accuracy

Object Temperature: ±1.1°F from 59°F to 95°F (±0.6·°C from
15°C to 35°C)
Ambient Temperature: 68°F to 78.8°F (20°C to 26ºC)
-76°F to 0°F: ±(2°F+0.1/degree) (-60°C to 0°C: ±(1°C+0.1/degree)
0°F to 149°F: ±2°F (0°C to 65°C: ±1°C) 149°F to 662°F: ±1.5% of
reading (65°C to 350°C: ±1.5% of reading)
Probe Accuracy

< 23°F: ±2°F (<-5°C: ±1°C)
23°F to 149°F: ±1°F (-5°C to 65°C: ±0.5°C)
>149°F (>65°C): ±1% of reading
Response Time

Less than 1 second
Display Hold Time

30 seconds
Display Resolution

0.5°F (0.2°C)
Emissivity Range

Factory set at 0.95 – adjustable 0.1 to 1.00 step 0.01
Battery & Battery Life

AAA x 2
IRT Mode: Typical 22 hrs; min. 20 hrs continuous use
(with laser)
COT Mode: Typical 207 hrs; min. 200 hrs continuous use
Sighting Method

Multi-beam laser
Dimensions

1.56in x 2.12in x 6.22in
(39.5mm x 53.9mm x 158mm)
Weight

5.64oz (160g) including batteries
Probe

Stainless steel, Length 3.74in (95mm), Dia 0.067in (1.7mm)
IP Rating

lP54
Certification

CE, NSF, NIST traceable
Bluetooth General Specifications

/
Chipset

Nordic nRF51822
Power Rating

DC 1.8V to 3.6V
Operating Temp

-22°F to 185°F (-30°C to 85°C)
Storage Temp

-40°F to 185°F (-40°C to 85°C)
Humidity (Non-Operating)

95% Maximum
Frequency and Power

2402-2480 MHz; 40 ch; 3.0mW
DeltaTrak manufactures products under an 1S0 9001:2015 registered quality management system

/
