DeltaTrak-FlashLink® AIR 4G/5G Real-Time In-Transit Logger-22493-01

  • Non-Lithium Battery
  • Next generation of global cellular communications real-time loggers with LCD using 4G/5G LTE with 2G backup
  • Monitors location, temperature, humidity, light, shock and air pressure
  • Temperature shown in °C
  • Proactively manage shipment location and conditions to reduce the risk of product loss due temperature excursions
  • FlashTrak Cloud Service platform offers different levels of access to optimize user experience and API integration into customer systems. FlashTrak receiver program allows shippers to customize access to alerts and shipment conditions
  • USB option to download PDF trip data should GSM network not be available
  • Light sensors alert you to unplanned security access which reduces and averts potential product theft during transportation
  • Maritime tracking service options ensure access to different modes of integrated supply chain data

Free shipping on orders over $50!

  • Check Mark Satisfaction Guaranteed
  • Check Mark No Hassle Refunds
  • Check Mark Secure Payments
GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal

Description

Applications: Real-time monitoring of export shipments, trip duration up to 15 days

The FlashLink AIR 4G/5G Real-Time In-Transit Logger utilizes the latest technology to protect domestic and export shipments of temperature sensitive products. DeltaTrak’s real-time devices provide the data shippers and receivers need to take immediate action if a temperature excursion occurs. With a single device, users can capture multiple types of sensor data, including location, temperature, humidity, shock, light, and air pressure

FlashLink AIR incorporates several enhanced features which offer new options for accessing data and contribute to greater ease of use. The addition of an LCD screen enables users to view trip data stored in the unit’s memory. A wider temperature measurement range of -30°C to 70°C (-22°F to 158°F) allows monitoring of commodities with diverse requirements.



Additional information

Brand

DeltaTrak.

Model

22493-01

Feature

Specification

Temperature Range

-30°C to 70°C (-22°F to 158°F)

Temperature Accuracy

±0.5°C from -10°C to 45°C
(±0.9°F from 14°F to 113°F),
±1.0°C (2.0°F) Other

Temperature Resolution

0.1°C/°F

Temperature Sensor Type

Internal Digital Temperature Sensor (NIST traceable)

Humidity Range

5% to 95% RH

Humidity Accuracy

±3% from 20% to 80%RH ±5% for other

Light Sensor Range

0 to 52000 lux

Light Detecton Accuracy

0.01 lux

Shock Sensor

0-8g height: 5-10cm

Usage Type

Single-use

Data Capacity

Max 28800 readings

Logging Interval

5 Min.

Data Upload Interval

15 Min.

Trip Duration

15-Day (based on logging and uploading intervals)

Cellular

Global LTE Cat-1 4G/5G network, with 2G Fallback

SIM

Internal Embedded (Global Data Roaming)

Power Source

Non-Lithium, NiMH, meets UN38.3

Battery Shelf Life

6 months

Logger Dimensions

4.05in x 2.41in x 1.18in (103mm x 61.3mm x 30mm)

Weight

4.9 oz (140 g)

Waterproof Rating

IP64

Certification

FCC, CE, UN38.3, RTCA/DO-160G, RoHS, NIST traceable temperature accuracy, WEEE

PDF Report Backup

Micro USB to USB cable to download full trip PDF report

/

DeltaTrak manufactures products under an ISO 9001:2015 registered quality management system
